Dab tsi yog Handheld Laser Vuam Tshuab
Lub tes tuav fiber ntau laser vuam tshuab yog lub cim tshiab ntawm cov khoom siv laser vuam. Nws belongs rau kev sib cuag welding. Nws tsis xav tau lub zog thaum lub sijhawm ua haujlwm. , uas melts cov khoom nyob rau hauv, thiab ces txias thiab crystallizes los ua ib tug weld.
Lub handheld fiber ntau laser vuam tshuab nyob rau hauv qhov sib txawv ntawm handheld vuam nyob rau hauv lub laser khoom kev lag luam, subverts hom kev ua hauj lwm ntawm cov tsoos laser welding tshuab, thiab hloov lub yav dhau los kho qhov muag txoj kev nrog rau handheld hom.
Qhov zoo ntawm Handheld Laser Vuam Tshuab
Wide welding ntau yam:Lub tes tuav lub taub hau yog nruab nrog 5m-10M thawj qhov muag fiber ntau, uas kov yeej qhov kev txwv ntawm qhov chaw ua haujlwm thiab tuaj yeem siv rau kev vuam sab nraum zoov thiab kev sib txuas ntev.
Yooj yim thiab yoog raws siv:Tes tuav laser vuam yog nruab nrog txav pulleys, uas yooj yim los tuav, thiab tuaj yeem hloov kho txhua lub sijhawm, tsis tas yuav tsum muaj cov chaw nres tsheb ruaj khov, dawb thiab hloov pauv, thiab tsim nyog rau ntau qhov chaw ua haujlwm.
Ntau txoj kev welding:Vuam ntawm txhua lub kaum ntse ntse tuaj yeem ua tiav: stitch vuam, taub qab vuam, ntsug vuam, tiaj tus vuam vuam, sab hauv vuam vuam, txheej txheej txheej vuam, thiab lwm yam. Vuam ntawm txhua lub kaum ntse ntse tuaj yeem ua tiav. Tsis tas li ntawd, nws tseem tuaj yeem ua tiav qhov txiav, vuam thiab txiav tuaj yeem hloov pauv dawb, tsuas yog hloov cov vuam tooj liab nozzle rau txiav tooj liab nozzle, uas yooj yim heev.
Zoo welding nyhuv:Tes tuav laser vuam yog kub-melt vuam. Piv nrog rau cov tsoos welding, laser vuam muaj lub zog ntau dua thiab tuaj yeem ua tiav cov txiaj ntsig zoo dua. , vuam qhov tob yog loj, lub melting yog txaus, nws yog ruaj khov thiab txhim khu kev qha, thiab lub zog ntawm lub vuam ncav cuag los yog txawm tshaj lub hauv paus hlau nws tus kheej, uas tsis tuaj yeem lav los ntawm cov tshuab vuam zoo tib yam.
Welds tsis xav tau kev sib tsoo:Tom qab ib txwm welding, cov ntsiab lus vuam yuav tsum yog hauv av kom ntseeg tau tias smoothness thiab tsis roughness. Tes tuav laser vuam tsuas yog qhia txog qhov zoo ntawm kev ua haujlwm: txuas txuas txuas, du tsis muaj ntses nplai, zoo nkauj tsis muaj caws pliav, thiab cov txheej txheem sib tsoo tsawg dua.
Tsis muaj consumables rau welding:Kev ua haujlwm vuam nyob rau hauv feem ntau cov neeg xav tau yog "sab laug-tes tsom iav, sab xis-tes clip vuam hlau". Txawm li cas los xij, nrog lub tes tuav laser vuam tshuab, vuam tuaj yeem ua tiav tau yooj yim, uas txo cov nqi ntawm cov khoom siv hauv kev tsim thiab ua.
Nrog ntau yam kev ceeb toom kev nyab xeeb, lub vuam cov lus qhia tsuas yog siv tau thaum qhov hloov pauv tau kov thaum nws kov cov hlau, lub teeb yuav raug kaw tom qab lub workpiece raug tshem tawm, thiab qhov kov hloov pauv muaj lub cev kub sensor. Kev nyab xeeb siab, ua kom muaj kev nyab xeeb ntawm cov neeg ua haujlwm thaum ua haujlwm.
Txuag tus nqi zog:Piv nrog arc vuam, tus nqi ua haujlwm tuaj yeem txo qis li ntawm 30%. Kev ua haujlwm yog qhov yooj yim thiab yooj yim rau kev kawm thiab kev kawm ceev, thiab cov txheej txheem ntawm tus neeg teb xov tooj tsis siab. Cov neeg ua haujlwm ib txwm tuaj yeem ua haujlwm tom qab kev cob qhia luv luv, thiab tuaj yeem ua tiav cov txiaj ntsig zoo vuam zoo.
Lub laser fais fab ntom ntom melts cov hlau, tshem tawm qhov yuav tsum tau ntaus arc; lub wobble muaj nuj nqi tshem tawm qhov yuav tsum tau weave lub hlaws manually; thiab nyob rau hauv ntau zaus, hlau pub yog tshem tawm tag nrho. Lub zog siab ntom ntom ua rau lub pas dej me me, tswj tau ntau dua.
Nrog rau kev tswj hwm ntawm laser tsis zoo, cov teebmeem kev kub ntxhov tau txo qis, ua rau cov txheej txheem nkag mus rau cov neeg ua haujlwm tsis muaj peev xwm thiab tso cai rau cov koom haum txhawb nqa lawv cov neeg ua haujlwm raws caij nyoog kom muaj nuj nqis ntxiv.
Cov cuab yeej kev ntseeg tau yog ib lub sij hawm muaj kev txhawj xeeb nrog tes tuav laser vuam. Lub tsev thaiv ntawm fiber ntau laser yog ib leeg-emitter diode, uas muaj lub neej ntev ntawm qhov kev txiav txim siab ntev dua li lub neej ntawm diode array lossis bar-stack lwm txoj. Cov twj tso kua mis yog hermetically kaw rau cov qauv kev sib txuas lus thiab tsis muaj kev cuam tshuam los ntawm cov av noo, plua plav, kev co, thiab qhov chaw ua haujlwm hnyav tshaj plaws.
Nrog rau tes tuav laser vuam txoj kev lag luam robustness, fiber ntau lasers yuav siv tau los ntxiv rau hauv paus Hoobkas automation, ntxiv kev txhim kho efficiency nyob rau hauv ntau lawm. Nrog rau qhov tawg tsis ntev los no hauv kev sib koom tes neeg hlau tshuab (cobots), theem pib ntawm lub Hoobkas automation yog nyob rau hauv ncav cuag ntawm ntau cov plag tsev. Cobots yog inherently synergistic nrog tes tuav laser vuam tshuab vim hais tias lawv yog tus nqi zoo thiab yooj yim rau siv thiab deploy. Cov neeg hlau qhov yooj yim ua ke nrog lub peev xwm ntawm tes tuav laser vuam tshuab ua rau nws tsim nyog rau cov khoom qis, cov khoom siv sib xyaw ua ke. Yog hais tias nws tuaj yeem welded los ntawm tes, nws zoo li yuav tau welded nrog ib tug cobot. Qhov no tuaj yeem txhim kho cov khoom siv laser txuas ntxiv los ntawm kev tso cai rau koj los preload ib feem fixture thaum lub cobot ua ib qho vuam ntawm ib qho kev sib cais.
Nyob ntawm qhov system, tes tuav laser vuam yog muaj nyob rau hauv configurations enabling mus txog rau 6- hli, puv welds.
Tsis tas li ntawd, qee qhov system configurations kuj siv tau rau kev tu ib feem. Qhov no tuaj yeem muaj txiaj ntsig zoo hauv kev npaj ib feem kom tshem tawm cov roj seem lossis cov khib nyiab los ntawm qhov chaw ua haujlwm.
Lub tes tuav laser lub peev xwm tu kuj tuaj yeem siv los tiv thaiv corrosion thiab passivate cov khoom tom qab vuam. IPG tau npaj qee qhov welds raws li ASTM B117-19, Kev Xyaum Ua Haujlwm rau Kev Ua Haujlwm ntsev tsuag (Fog) Apparatus thiab xa lawv mus rau SMS. Ib sab-los-sab piv ntawm ib lub laser-passivated weld thiab ib qho kev tsis sib haum xeeb tau pom tias kev ua tiav ntawm laser passivation.
Txawm hais tias lub laser tuav tau yooj yim siv thiab muaj cov yam ntxwv ntawm kev nyab xeeb, nws tseem ceeb heev kom nco ntsoov tias nws yog ib qho khoom siv muaj zog heev. Thaum siv lub laser tuav tes, nco ntsoov tias cov kab teeb tuaj yeem ua rau muaj kev phom sij rau lub cev thiab qhov muag. Lub laser vuam beam tsis pom, yog li koj tsis tuaj yeem tso siab rau qhov pom kev pom los lav kev nyab xeeb.
Thaum cov tshuab no yog Class IV lasers, cov yam ntxwv kev nyab xeeb tau muab tso rau hauv cov tshuab los tiv thaiv koj. Thaum tsim kom muaj kev ruaj ntseg laser, qhov pib zoo yog los tshuaj xyuas ANSI Z136.1 (2014), Kev Nyab Xeeb Kev Siv Lasers. Ntxiv nrog rau kev nyab xeeb laser, koj yuav tsum tau ua raws li cov kev cai welding ib txwm muaj.
Nov yog qee qhov kev cai dav dav kom ua raws li:
• Ua txhua yam haujlwm ntawm laser vuam nyob rau hauv ib cheeb tsam uas tswj tau lub laser (LCA)—ib lub teeb nruj nrog cov hluav taws xob interlocks uas tua lub laser beam thaum qhib lub qhov rooj.
• Hnav cov khaub ncaws uas tsis muaj hluav taws kub, lub tsho ntev, thiab cov khaub ncaws vuam. Txhua tus neeg nyob hauv LCA yuav tsum siv cov cuab yeej tiv thaiv tus kheej, suav nrog cov tsom iav kev nyab xeeb laser ntsuas rau hom laser thiab lub kaus mom hlau ib txwm siv.
• Ua raws li cov txheej txheem kev nyab xeeb kev khiav hauj lwm, coj mus rau hauv tus account tias lub teeb laser tuaj yeem cuam tshuam.
• Tsis txhob ua haujlwm ntawm tes tuav laser welder yam tsis tau paub txog kev nyab xeeb thiab cov txheej txheem uas tau sau tseg hauv phau ntawv qhia khoom siv, uas yuav kom koj ua raws li cov lus qhia hauv Z136.1.
Cov yam ntxwv tseem ceeb ntawm Handheld Laser Welder
Nyob rau hauv lub handheld laser system, cov yam ntxwv yog feem ntau. Lub tshuab laser tau muab tso rau hauv ib lub tsev sib txawv, thaum cov hluav taws xob tshwm sim yog xa mus rau ib rab phom welding handheld los ntawm cov khoom siv kho qhov muag. Cov phom vuam no feem ntau yog nruab nrog lub peev xwm nrhiav kom pom, tso cai rau qhov nrawm nrawm ntawm cov cuab yeej hauv qhov xav tau qhov chaw vuam.
Thaum lub sij hawm vuam txheej txheem, lub laser heats / melts cov ntaub ntawv ib puag ncig thiab tom qab fuses lawv ua ke thaum lub sij hawm txias.
Cov phom vuam yog nruab nrog lub taub hau tshuaj tsuag, khawm khawm, thiab ntsuas kub. Tag nrho cov nyiaj no ua rau muaj txiaj ntsig zoo lossis ergonomic tsim ua rau muaj kev saib xyuas me me thiab kev ruaj ntseg siab. Kev tswj xyuas nruj me ntsis ntawm cov cuab yeej no muaj tshaj qhov tob thiab dav ntawm cov vuam ua rau nws yog qhov kev xaiv nrov rau kev lag luam uas yuav tsum tau ua kom tiav thiab du.
Chav tsev cais ntawm Handheld Laser Welder yog qhov chaw tsim hluav taws xob thiab lub zog. Cov khoom no muaj cov neeg siv-phooj ywg vaj huam sib luag rau kev siv yooj yim ntawm lub tshuab qhov chaw. Nws feem ntau yuav zoo li lub tshuab hauv daim duab qhia hauv qab no.
Dab tsi yog Txoj Cai ntawm Tes Tuav Laser Vuam Tshuab?
High voltage tsav lub xenon teeb kom emit lub teeb, lub YGA crystals ntsia ua ke yog illuminated los ntawm lub laser, resonantly resonate los ntawm tag nrho cov reflection thiab semi-reflection diaphragm, thiab ces input mus rau lub optical fiber los ntawm lub beam splitter thiab optical rooj vag, thiab thaum kawg. tsom lub laser mus rau ib qho point.
Lub zog ceev ntawm lub dav hlau focal tuaj yeem ncav cuag 10 5 -1013 w/cm2. Lub tes tuav laser vuam tshuab siv cov yam ntxwv ntawm cov kev taw qhia zoo heev thiab lub zog siab ceev ntawm lub laser beam ua haujlwm.
Lub laser beam yog concentrated nyob rau hauv ib tug me me cheeb tsam, thiab nyob rau hauv ib tug luv luv lub sij hawm ntawm lub sij hawm, lub zos tshav kub qhov chaw uas muaj zog concentration yog tsim nyob rau hauv lub welded ib feem, yog li ntawd lub welded khoom yog melted thiab ib tug ruaj welding qhov chaw thiab seam. tsim.
Cov qauv muaj nyob rau ntawm LightWELD lub zog hluav taws xob zoo li cov uas pom ntawm cov khoom siv hluav taws xob ib txwm muaj. Lawv tau raug tsim los ua haujlwm nrog qee cov ntaub ntawv thiab thicknesses. IPG chav tsev yog tsim los tuav 74 vuam hom, thiab preset hom muaj nyob rau hauv lub chav tsev kom nws npaj txhij siv raws li tau txais.
Qee hom yuav paub txog cov welders. Piv txwv li, Fisher tau hais tias cov cuab yeej muaj qhov txuas txuas ntxiv-yoj hom uas lub laser ua haujlwm tag nrho lub sijhawm kev koom ua ke tshwm sim; ib hom mem tes thaum txo cov cua sov yog tsim nyog; thiab tack thiab stitch hom nyob rau hauv uas lub laser powers rau thiab tawm los ua noncontinuous welds. (Laser welding twb muaj qhov zoo ntawm kev tsim ib cheeb tsam uas muaj cua sov tsawg heev ua tsaug rau lub peev xwm tsom lub teeb laser - nrog rau qhov chaw loj ntawm 150 µm.)
Lub tshuab laser vuam kuj tuaj yeem siv los koom nrog ntau hom hlau:
- Cov hlau me me, stainless hlau, thiab txhuas mus txog 4 hli (0.157 nyob rau hauv.) rau ib leeg-sab weld thiab 10 hli (0.394 hauv.) rau ob sab weld.
- Tooj liab mus txog 1 hli (0.039 nyob rau hauv.) rau ib leeg-sab weld thiab 2 hli (0.079 nyob rau hauv.) rau ob sab weld.
- Fisher tau hais ntxiv tias ntau lub tuam txhab tsim cov hlau pib siv thev naus laus zis thiab muab kev tawm tswv yim rau IPG engineers, lub tuam txhab yuav tuaj yeem hloov kho lossis qhia cov qauv tshiab thiab daim ntawv thov zaub mov txawv los pab cov vuam. Cov "kho dua tshiab," raws li Fisher tau piav qhia, yog rub tau thiab nruab tau yooj yim ntawm kev sib txuas hauv Ethernet rau lub PC.
- Ib qho ntawm cov kev thuam tseem ceeb ntawm laser vuam yog tias nws yuav tsum tau ua kom nruj nruj heev vim tias cov tshuab feem ntau tsis tuaj yeem them nyiaj rau qhov khoob hauv cov khoom ua haujlwm, ib yam dab tsi tshwm sim ntau zaus vim yog cov khoom siv pleev lossis lub khw muag khoom tsis muaj qhov tseeb fabricating technology. Txhawm rau hais txog qhov tsis txaus ntseeg no, IPG tau hloov kho lub wobble muaj nuj nqi siv nyob rau hauv tsis-tes tuav laser vuam rau cov cuab yeej phau ntawv.
Tes tuav Laser Welder Safety
Tes tuav laser vuam tej zaum yuav txawv dua li ib txwm arc vuam, tab sis cov txheej txheem muaj qee qhov sib tshooj. Ib tug welder tseem yuav tsum tau hnav cov khaub ncaws uas tsis muaj hluav taws xob nrog lub tes tsho ntev, cov hnab looj tes vuam, thiab lub kaus mom hlau vuam. Tab sis ua ntej cov ntaub thaiv npog los ntawm lub welder lub ntsej muag, nws yuav tsum tau muab tso rau ntawm ob lub laser-zoo tsom iav, uas muab kev tiv thaiv siab heev thiab cia tus welder pom lub pas dej weld los ntawm lub vuam hood lens. Qhov chaw fais fab no yog tsim cov Class IV laser tom qab tag nrho.
Txhua lub tuam txhab tsim khoom lag luam uas ua haujlwm ntawm tes tuav laser vuam kuj yuav xav muab cov ntaub ntawv laser-kev nyab xeeb los tiv thaiv lwm tus hauv khw. Qhov no tuaj yeem yog chav tsev nrog lub qhov rooj hloov lossis ib lub xovtooj ntawm tes uas tsim los nrog cov ntaub thaiv lub teeb lossis cov ntaub qhwv lub siab, zoo li lub xov tooj ntawm tes welding. Nyob rau hauv ob qho xwm txheej, thaum tib neeg nkag mus rau thaj chaw ua haujlwm thaum lawv tsis tas yuav tsum nyob ntawd, lub zog laser tam sim ntawd kaw.
Lub LightWELD chav kuj tseem muaj qee qhov ua tau zoo los xyuas kom muaj kev nyab xeeb. Lub kaw lus tau tsim los nrog kev sib cuam tshuam uas yuav tsum tau siv lub taub hau vuam kom sib cuag nrog cov khoom siv thaum vuam. Yog hais tias lub taub hau tsis kov ib feem, lub laser kaw. Qhov no ua kom lub laser yog tsom rau cov hlau workpiece. Tsis tas li ntawd, rab phom vuam yuav tsum tau siv ob kauj ruam txheej txheem: lub pob kom ua haujlwm thiab lwm lub pob kom tua hluav taws.
Kev sib piv ntawm Handheld Laser Vuam Tshuab thiab Argon Arc Vuam
Kev sib piv siv zog:Piv nrog rau cov tsoos arc vuam, tes tuav laser vuam tshuab txuag txog 80% ~ 90% ntawm hluav taws xob, thiab cov nqi ua haujlwm tuaj yeem txo los ntawm 30%.
Kev sib piv ntawm cov nyhuv vuam:Laser tes tuav vuam tuaj yeem ua tiav cov hlau tsis sib xws thiab cov hlau tsis sib xws. Qhov ceev yog ceev, lub deformation yog me me, thiab lub tshav kub cuam tshuam cheeb tsam yog me me. Weld seam yog zoo nkauj, du, tsis muaj / tsawg porosity, thiab tsis muaj kuab paug. Lub handheld laser vuam tshuab yuav siv tau rau me me qhib qhov chaw thiab precision vuam.
Kev sib piv cov txheej txheem tom qab:Thaum tshav kub kub input thaum lub sij hawm laser tes tuav welding, me me deformation ntawm lub workpiece, zoo nkauj welding nto yuav tau txais, tsis muaj los yog tsuas yog kev kho mob yooj yim (nyob ntawm seb qhov yuav tsum tau ntawm cov vuam nto nyhuv). Lub handheld laser vuam tshuab tuaj yeem txo tus nqi zog ntawm cov txheej txheem polishing loj thiab qib.
Tej yam yuav tsum tau xav txog thaum yuav ib tug Handheld Laser Welder
Lub zog thiab kev ua haujlwm
Laser vuam tshuab yuav tsum tsis txhob txiav txim rau lawv lub zog laser ib leeg. Vim lub laser beam lub zog ntau dua, 1000W-2000W laser yog ntau tshaj txaus rau feem ntau cov hlau.
Xav txog lub handheld laser welding tshuab tau tshaj tawm tsis tu ncua thiab ncov lub zog. Feem ntau cov lasers tsuas yog ua haujlwm ntawm lawv cov zis siab tshaj plaws rau ob peb feeb. Ib tug 2500W ncov fais fab laser welder yuav rov qab mus rau ~ 1500W tom qab.
Portability thiab tsim
Portability yog qhov muag khoom loj rau cov khoom siv laser vuam. Cov dej num loj yuav tsum tau txav mus los ntawm cov welder kom haum rau cov khoom ua haujlwm.
Xaiv lub laser welder uas tuaj yeem txav tau yooj yim nyob ib puag ncig thiab tsis hnyav dhau lossis hnyav. Tom ntej no, koj xav tau ib qho qauv tsim uas tsis muaj qhov cuam tshuam uas tuaj yeem yooj yim puas hauv kev thauj mus los.
Yooj yim ntawm kev siv
Lub tshuab laser vuam yuav tsum raug kho raws li lwm yam cuab yeej. Nws yuav tsum tsis txhob xav tau phau ntawv qhia nyuaj thiab tedious los ua haujlwm.
Xaiv lub tshuab vuam uas los nrog cov kev tswj tau yooj yim thiab kev xav.
Nqe thiab tus nqi
Thaum muas lub laser welder, nco ntsoov xav txog koj cov kev xav tau kev lag luam. Lub tshuab kim uas siv tsis tu ncua muaj nqi ntau dua li qhov kev xaiv qis uas tsis tau siv ntau zaus.
Kev lag luam khoom siv laser yog tag nrho ntawm cov tshuab uas muaj ntau yam ntawm tus nqi hwm tab sis cov uas tsis tau siv los ntawm cov neeg siv khoom.
Kev khaws cia zoo
Laser vuam tshuab yog cov khoom siv rhiab heev; noo noo thiab plua plav ingress tuaj yeem cuam tshuam kev ua haujlwm thiab ua rau cov khoom siv sab hauv puas.
Tsis tas li ntawd, nyob rau hauv pem teb Hoobkas, xyuas kom meej tias cov hlau me me thiab cov khib nyiab tsis nkag mus rau hauv lub tshuab laser vuam.
Cable tswj
Lub optical fiber cable txuas lub vuam phom rau lub laser system yog tsis yooj yim sua. Khoov ntawm cov kaum ntse ntse los yog khiav dhau ib qho yuav ua rau nws tsis zoo dua.
Tes & qhov muag tiv thaiv
Yuav tsum hnav zoo tes thiab qhov muag tiv thaiv. looj tsom iav dub thiab hnab looj tes tiv thaiv hluav taws yog koj cov phooj ywg.
1 - lightweld xr handheld laser vuam tshuab
LightWELD XR yog fiber ntau laser vuam system los ntawm IPG Photonics thiab cov neeg ua haujlwm paub txog hauv kev lag luam laser daws.
Tus qauv XR ncav cuag 2500W ntawm lub siab tshaj plaws laser lub zog, muaj cov nozzles hloov tau, qhov zoo nkauj 60-micron qhov chaw loj, thiab siab dua hlau nkag.
IPG Photonics tseem muag cov qauv qis kawg hu ua LightWELD XC uas ua tau zoo ib yam tab sis tsis muaj ntau yam kev txhim kho lub neej zoo.
2 - Han's handheld laser welder hw-d
Tom ntej no, peb muaj lub compact handheld laser vuam tshuab, HW-D los ntawm Han's Laser Corporation.
Qhov no ntau yam laser welder tuaj yeem teeb tsa nrog peb lub zog laser teeb tsa (1kW, 1.5kW, thiab 2kW). Han qhov kev thov rau lub koob meej yog nws qhov zoo siab 3-hauv-1 laser functionality. Nws muaj hlau vuam, txiav, thiab tu lub peev xwm uas ntxias txhua tus tswv lag luam.
Han's Laser tsis tawm los hloov laser txiav tshuab. Hloov chaw, nws muaj ntau lub tshuab uas tuaj yeem siv rau kev txiav yooj yim.
Qhov no all-in-one handheld laser welding system los ntawm qhov hnyav ntawm 600 lbs. (275 kg). Txawm hais tias nws tseem yog lub xov tooj ntawm tes, nrog cov log hauv qab ntawm lub tshuab, qhov hnyav yuav ntau dhau rau ib tus neeg teb xov tooj los thawb ib ncig.
3 - Baison laser fsc handheld vuam tshuab
Baison Laser yog lub chaw tsim khoom mus sij hawm ntev ntawm fiber ntau laser tshuab. Nrog rau ntau tshaj 20 xyoo ntawm kev lag luam kev lag luam, lawv tsis cuam tshuam vuam zoo thiab tshuab versatility.
Lawv handheld laser vuam tshuab yog tsim los ntawm hauv av los xyuas kom meej ib tug yooj yim, hassle-dawb vuam txheej txheem. Nws lub zog txias txias ua kom tsis muaj suab nrov tsis tu ncua ua haujlwm. Lub Baison laser welder kuj tuaj nrog cov txheej txheem kev nyab xeeb.
Baison sawv tawm vim nws qhov zoo ntawm laser optics thiab lub cev muaj zog. Ib tug zoo laser beam ncaj qha qhia qhov zoo nyob rau hauv tej yam khoom siv vuam.
Baison kuj tseem muaj cov tshuab laser vuam tsis siv neeg (robots) rau cov neeg uas tab tom nrhiav ib yam dab tsi hwm.
4 – Hs laser hw-1500 lightwelder
HS Laser's HW-1500 yog lub tshuab me me fiber ntau laser vuam nrog lub zog 1500W laser. Sawv siab ntawm tsuas yog 21 ntiv tes nrog qhov ntev ntawm 26 ntiv tes. Nws yog sleek, ncaj ncaj laser vuam tshuab nrog tus tsim ergonomic thiab xis vuam phom tuav.
Lub HW-1500 tsim ib qho ntawm cov welds huv tshaj plaws. Lub laser beam nyob rau hauv handheld laser vuam tshuab tiag tiag ci thaum vuam hlau. Nws txhawb nqa ntsug vuam, nyiaj siv ua haujlwm vuam, taub qab vuam, thiab lwm yam.
HS Laser tau tsim nws cov handheld laser welder los txhim kho qhov zoo ntawm laser vuam ntxiv. Qhov no tau ua rau qhov tshwj xeeb weld zoo uas yog qhov zoo, yog tias tsis zoo, tshaj qhov kev sib tw.
Vim nws qhov me me, cov theem hloov cua txias tsis tuaj yeem ncav cuag nws ob txhais ceg. Qhov loj me me txwv nws qhov kev ua haujlwm kub tsuas yog 104 degree F (40 degree). Qhov kev txwv kub no yuav ua rau kev ua haujlwm vuam thaum lub caij ntuj sov, tshwj xeeb tshaj yog rau cov cheeb tsam ze rau ntawm txoj kab nruab nrab.
5 – Photonweld-a1600
PhotonWeld A1600 yog ib qho nruab nrab ntawm txoj kev laser vuam tshuab. Nws yog compact tab sis tsis dhau me me, muaj cua txias txaus tab sis tuaj yeem tau txais suab nrov me ntsis, thiab tsis muaj lub zog laser nws cov neeg sib tw muab.
Yuav kom paub meej, ntawm 1600W ntawm lub zog, A1600 yog qhov ua tau zoo, thiab xav txog lub zog ceev ntawm cov tshuab laser vuam, nws yuav ua tau zoo heev hauv kev ua haujlwm feem ntau.
Tab sis ib yam uas thawb PhotonWeld mus rau saum tsib yog nws qhov yooj yim thiab yooj yim-rau-kev tswj vaj huam sib luag. Qhov no yog tsis muaj frills laser welding tshuab txhais tau tias kom koj nce thiab khiav hauv lub sijhawm luv tshaj plaws.
Tsis tas li ntawd, A1600 los nrog pre-programmed weld nqis rau kev teeb tsa ceev. Koj tuaj yeem txuag tau qhov chaw siv nquag thiab yooj yim hloov mus rau lawv nrog ob peb clicks.
